SUPERVISORY SWITCHES (FOR OS&Y VALVES)
Product Line
| Model : | 05 OSYS-U1 (1 Set SPDT) |
| Model : | 05 OSYS-U2 (2 Set SPDT) |
Description
Designed to supervise open condition of OS&Y valves.Mounts conveniently to ½” through 12″ OS+Y valves. NEMA 4 and NEMA 6P enclosure (IP67).
Red enamel finish.
Approvals: U.L. listed and FM approved.
General Specification
| Cover | Die-cast |
| Base | Die-cast zinc |
| Contacts | One or Two sets SPDT (Form C) |
| Power Consumption | 15.0 amp at 250 VAC 2.5 amps at 30 vdc. |
| Service Pressure | 250 psi Maximum |
